A defined role in your monitoring routine.
The S3A brings MLSS and automated settlement measurements together in a compact instrument for routine wastewater laboratory and operational testing. It uses a representative 210 ml sample.
An operator can start the 30-minute settlement cycle and return to the completed outputs. This supports a repeatable routine for comparing site samples, while preserving the laboratory’s existing responsibilities and procedures.
From a representative sample to a recorded result.
Prepare the sample
Collect a representative sample using the site’s procedure. Use a 210 ml sample and confirm that the expected MLSS is within the specified 50–6,500 mg/L range. Readings above 6,500 mg/L are indicated as INF.
Run the test
S3A provides an MLSS result in approximately 10 seconds, followed by a 30-minute unattended settlement cycle. Standard outputs include SVI, settled sludge level, supernatant clarity and floating sludge.
Review in context
Review completed measurements alongside the sample identity and site observations. Store up to 28 completed results for each of three internal locations, with date and time.
Keep operational and compliance testing clear
S3A is an operational analyser. Required statutory, accredited or compliance laboratory work must continue under the procedures that apply to the site.
Calibration and optional measurements
Calibrate with a site-specific sample of known MLSS between 2,000 and 4,000 mg/L. Repeat after large changes in sludge characteristics. SSVI and SSSL require the optional stirrer module.
Optional connection to a client system.
Specify optional MODBUS RTU over two-wire RS-485 when ordering. Read functions 03/04 provide supported readings to a compatible client system; dashboards and integration are client-provided. Function 06 is limited to Holding Register 40001 for the slave ID (1–247), not measurement writes or test control.
Operational measurement, not a replacement for required laboratory analysis.
S3A supports operational checks of activated sludge. Required compliance sampling, regulatory testing and laboratory analysis must still follow the procedures that apply to the site.
Operate indoors in a safe area at 0–45°C, in noncondensing conditions and away from direct and reflected sunlight. Follow the current manual and the treatment works’ safety and sampling procedures.
